The LaminAir System

"for precise air distribution"

The LaminAir™ Perforated Air Distribution System brings "a clean room environment" to ordinary air conditioned areas.  The system uses a standard T-bar suspended ceiling grid with LaminAir™ panels to form a room-sized air diffuser.

Compare the Benefits

Design Flexibility - Floor plan layouts and air conditioning capacity can be modified without altering the air distribution system.  There is no ductwork or individual ceiling diffusers to change because the entire ceiling is an air diffuser.

Precise Temperature Control - On air conditioning applications that require temperature control within ±0.1F° no other system compares.  To achieve this requires precise control of air mixing and distribution.  With LaminAir™ ceiling panels, supply air from the air conditioning unit is distributed and mixed in a pressurized plenum above the ceiling panels.  When the supply air passes through the panels it mixes with room air.  This mixing takes place within twelve inches of the ceiling and results in uniform room temperature.

Draft Free Air Conditioning - The LaminAir™ perforated ceiling completely eliminates drafts common to conventional air supply systems.  The air diffuses, uniformly through the ceiling panels and into the room at low velocity.

Reduced Indoor Air Pollution - Indoor air quality is improved because air turbulence is nonexistent.  Turbulent air causes pollution to be recirculated in eddy currents, within the occupied space, preventing the pollutants from being filtered out or diluted with outside air.

Operating Cost - The LaminAir™ distribution system operates at a lower static pressure than equivalent ducted air distribution systems.  Less horsepower is needed to circulate the air, resulting in lower operating cost.

Installed Cost - Less than an equivalent insulated metal duct system.

A Comparison of Air Distribution Systems

Conventional System - Conventional systems create turbulence which causes drafts, temperature variations and keeps pollutants suspended in the room air.

LaminAir™ System-  The LaminAir™ air distribution system delivers non-turbulent, draft free air, at uniform temperature.

(Click on graph for a larger view.)

Click here for pricing and more information.

 .            .
